304 Stainless Steel Drinking Water Filling Machine 300bph for 5 Gallon Barrel

Name: 304 Stainless Steel Drinking Water Filling Machine 300bph for 5 Gallon Barrel
Brand: Labelong
Price: 20000 USD

304 Stainless Steel Drinking Water Filling Machine 300bph for 5 Gallon Barrel Manufactures

Brand Name : Labelong

Model Number : RGF-300

Certification : CE

Place of Origin : China

MOQ : One set

Price : USD20000-50000/SET

Payment Terms : T/T OR L/C

Supply Ability : 50-100SET/YEAR

Delivery Time : 20-40 days

Packaging Details : Wooden case

Product name : 5 Gallon Filling Machine

Filling liquid : Mineral water

Capacity : 300BPH

Dimension(L*W*H) : 2200*2100*2200MM

Function : Bottle Washing Filling Capping

Control : PLC

Bottle type : PET bottle

Automatic grade : Automatic

Type : Filling Machine

After-sales service provided : Engineers available to service machinery overseas

Condition : New

Packaging material : Plastic

Packaging type : Barrel,Bottles

Contact Now

304 Stainless Steel 300bph Automatic 5 Gallon Barrel Bottle Drinking Water Filling Machine

Our QGF complete 5 gallon barrel pure,mineral water filler line mainly consists of 7 parts. They are respectively:
1. De-capping machine
2. External barrel brushing machine
3. Bottle feeding machine
4. Washing, filling, capping machine
5. Cap elevator
6. Lamp checker
7. Conveyor

The QGF series barreled water filling line is mainly used to produce bottled water with volume from 3 gallon to 5 gallon.And different models can offer production capacity from 100 to 2000BH/H.The whole production process operates as follows:Empty barrel are convenyed stably by conveying belt into decapping machine,which will remove bottle caps.Those caps can be recycled after being cleaned and disinfected.Then barrel are conveyed into the extemal brush washing machine to take all-round rinsing with hot alkali and pure water.After rinsed,barrel will be sent to rinsing filling capping machine,where bottles are rinsed inside with hot alkali,disinfectantliquid and pure water.And then barrel is filled with pure water provided by water treatment system.Then after capped,those barreled water is sent to shrink packing machine in which shrink packaging of caps is done.The whole production process is controlled by PLC,so this barreled water production line is automatic,Through control panel,users can monitor visually working conditions of each machine section and operate conveniently.

5 Gallon Filling Machine Parameter

Model	WFC-100	WFC-200	WFC-300	WFC-450	WFC-600	WFC-900	WFC-1200
Rated Production Capacity (bph)	100	200	300	450	600	900	1200
Installed Capacity	1.3	1.7	3.8	3.8	7.5	9.7	13.5
Related Voltage(V)	380V/HZ	380V/HZ	380V/HZ	380V/HZ	380V/HZ	380V/HZ	380V/HZ
Weight (kg)	680	800	1500	2100	3000	3500	4500

304 Stainless Steel Drinking Water Filling Machine 300bph for 5 Gallon Barrel

Configuration List:
304 Stainless Steel Drinking Water Filling Machine 300bph for 5 Gallon Barrel

Our factory

304 Stainless Steel Drinking Water Filling Machine 300bph for 5 Gallon Barrel

Shipping photo
